Product video
PRODUCT DETAILS
* PLC control system with continuously feeding capacity, complete the baling and output automatically.
* Convenient for transportation, save store and transportation cost;
* Application: suitable for compress aluminum cans, tin cans, paint bucket, etc.
Technical Parameters
| Model | Hydraulic power（Ton） | Feed opening size（L*W）mm | Bale size（L*W*H）mm | Power（KW/HP） | Bale weight (KG) | Capacity（Ton/hr） |
| JPY-T60W | 60 | 900*430 | 430*280*(150-250) | 22/30 | 15-20 | 0.5-1 |
| JPY-T80W | 80 | 1000*450 | 450*300*(150-250) | 22/30 | 18-25 | 0.8-1.5 |
| JPY-T100W | 100 | 1100*500 | 500*330*(200-300) | 30/40 | 20-32 | 1-1.8 |
| JPY-T120W | 120 | 1200*550 | 550*400*(250-350) | 37/50 | 30-40 | 1.5-2.5 |
