Product video
PRODUCT DETAILS
* The closed type door with lifting up and down structure, one time bale-out, no need to move the bale in time after the bale is out.
* High-strength bale out, double-cylinder automatic door opening and closing device, safe and reliable.
* Continuous feeding and compression, good water accumulation effect with centralized drainage system to prevent pollution of the site environment.
* PLC automatic control system, unmanned operation with safety interlock, and it can be connected to the conveyor line.
Technical Parameters
| Model | JPW60JS | JPW80JS | JPW100JS | JPW120JS | JPW150JS | JPW200JS |
| Compression force（Ton） | 60 | 80 | 100 | 120 | 150 | 200 |
| Bale size（L*W*H）mm | 500*500*(300-1100) | 720*720*(300-1100) | 750*850*(300-1100) | 900*800*(300-1100) | 1000*900*(300-1100) | 1100*1100*(300-1100) |
| Feed opening size（L*W）mm | 1000*500 | 1100*720 | 1200*750 | 1400*900 | 1600*1000 | 1800*1100 |
| Capacity | 4-7 | 6-9 | 8-12 | 10-14 | 13-17 | 16-20 |
| Average moisture content after pressing | ≤60% | ≤60% | ≤60% | ≤60% | ≤60% | ≤60% |
| Power（Kw/Hp） | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 60/80 |
| Machine size（L*W*H）mm | 6412*1432*2100 | 6520*1610*2100 | 6700*1650*2100 | 6900*1780*2400 | 7390*1800*2750 | 7650*2000*2750 |
